FURNITURE CASTOR 30 MM DIAMETER 15 KG MAX LOAD - S12C30

REF: 23015

Swivel furniture castor wheel with plate, 30 mm diameter.

This castor wheel is composed of a mounting in galvanised pressed steel housing.

Its roller is in anthracite-grey rubber, which has the feature of being non-marking.

Disreet and sober, this castor wheel knows how to adapt marvellously to all your small pieces of furniture under 15 kg. It is perfect for bedside tables, shelves, small armchairs...



Payment Secure
Add to Compare Remove from Compare

Technical sheet

  • Diameter of the wheel in mm 42

  • Load capacity in kilograms 20

  • Material of the tread Polypropylene

  • Type of bearing Plain bore hub

  • Type fixation Pivoting to plate (plate)

  • Height of the roulette in mm 56

  • Dimension plate in mm 54X40

  • Distance between axes in mm 44X30

  • Diameter of fixation in mm M6

  • Wheel width in mm 15

  • Width of the bearing band in mm 15

  • Offset in mm 17

  • Dimensions in mm 38

  • Maximum speed in km/h 4

  • Minimum / Maximum Temperature in °C -20/+80

  • Weight 0.083 Kg
