• New
Castor RECESS MOUNT FOR WOOD SLIDING DOOR 25 MM WIDE LOAD 80 KG - NAPO 25 • Caujolle
How to choose your roulette?

Castor RECESS MOUNT FOR WOOD SLIDING DOOR 25 MM WIDE LOAD 80 KG - NAPO 25

REF: 99481

Castor unique recessed caster with brake for 25 mm panels

This recessed caster, with its innovative half-circle design, is ideal for beds, panels, mobile partitions, cabinets, and furniture. Its robust design consists of two zamak shells that house a non-staining wheel made of PVC.

It stands out for its integrated brake system (ON/OFF buttons). Specifically designed for 25 mm thick panels, its installation requires cutting the wood (which can be done with a jigsaw) following the provided assembly plan.

Payment Secure
Add to Compare Remove from Compare

Technical sheet

  • Diameter of the wheel in mm 60

  • Load capacity in kilograms 80

  • Material of the tread PVC

  • Type of bearing Plain bore hub

  • Height of the roulette in mm 70

  • Specificities Non-staining

  • Wheel width in mm 15

  • Uses Castor for furniture

  • Width of the bearing band in mm 15

  • Maximum speed in km/h 4

  • Minimum / Maximum Temperature in °C -20/+70

  • Weight 0.189 Kg
