Castor MINI EXTRA-LOW WITH STRONG BRAKE LOAD CAPACITY 35 MM DIAMETER 53 MM HEIGHT LOAD 100 KG - EXTRA SURB 35 PAF • Caujolle
  • Castor MINI EXTRA-LOW WITH STRONG BRAKE LOAD CAPACITY 35 MM DIAMETER 53 MM HEIGHT LOAD 100 KG - EXTRA SURB 35 PAF
  • Castor MINI EXTRA-LOW WITH STRONG BRAKE LOAD CAPACITY 35 MM DIAMETER 53 MM HEIGHT LOAD 100 KG - EXTRA SURB 35 PAF
  • Castor MINI EXTRA-LOW WITH STRONG BRAKE LOAD CAPACITY 35 MM DIAMETER 53 MM HEIGHT LOAD 100 KG - EXTRA SURB 35 PAF
  • Castor MINI EXTRA-LOW WITH STRONG BRAKE LOAD CAPACITY 35 MM DIAMETER 53 MM HEIGHT LOAD 100 KG - EXTRA SURB 35 PAF
How to choose your roulette?

Castor MINI EXTRA-LOW WITH STRONG BRAKE LOAD CAPACITY 35 MM DIAMETER 53 MM HEIGHT LOAD 100 KG - EXTRA SURB 35 PAF

REF: 99273

Castor extra low with a diameter of 35 mm and a height of 53 mm. This low height is its main characteristic, allowing it to be installed on many supports without significantly raising the work surface. The action of the brake is very important and will prevent rotation even on sloped surfaces. The wheel is bolted in case it needs to be replaced after many years of wear. The material used is polyurethane, which has maximum resistance characteristics in terms of abrasion resistance.

Payment Secure
Add to Compare Remove from Compare

Technical sheet

  • Diameter of the wheel in mm 35

  • Load capacity in kilograms 100

  • Material of the tread Polyurethane

  • Type of bearing Bearing ball bearing

  • Type fixation Pivoting to plate (plate)

  • Height of the roulette in mm 53

  • Specificities Heavy load

  • Dimension plate in mm 60x60

  • Distance between axes in mm 45x45

  • Diameter of fixation in mm M6

  • Wheel width in mm 27

  • Brake With brake

  • Uses Castor industrial

  • Width of the bearing band in mm 27

  • Offset in mm 14

  • Dimensions in mm 34

  • Maximum speed in km/h 1

  • Minimum / Maximum Temperature in °C -20/+80

  • Weight 0.244 Kg

You might also like

EXTRA-LOW CASTOR WHEEL HEAVY LOAD 100KG SURB 35 P • Caujolle
  • Diameter of the wheel in mm 35
  • Load capacity in kilograms 100
  • Material of the tread Polyurethane
  • Type of bearing Bearing ball bearing
  • Type fixation Pivoting to plate (plate)
  • Height of the roulette in mm 65
  • Specificities Heavy load
    Non-staining
  • Dimension plate in mm 60x48
  • Distance between axes in mm 48x35
  • Diameter of fixation in mm M6
  • Wheel width in mm 27
  • Width of the bearing band in mm 27
  • Offset in mm 12
  • Dimensions in mm 30
  • Maximum speed in km/h 1
  • Minimum / Maximum Temperature in °C -20/+80
handling-and-industry-castor-wheels

EXTRA-LOW CASTOR WHEEL HEAVY LOAD 100KG SURB 35 P

Industrial castor wheel 35 mm diameter, swivel plate.

Details
Add to Compare Remove from Compare
Castor EXTRA-LOW HEAVY-DUTY CASTOR DIAMETER 50 MM HEIGHT 72 MM LOAD 150 KG - SURB 50 PAF • Caujolle
  • New
  • Diameter of the wheel in mm 50
  • Load capacity in kilograms 150
  • Material of the tread Polyurethane
  • Type of bearing Bearing ball bearing
  • Type fixation Pivoting to plate (plate)
  • Height of the roulette in mm 71.5
  • Specificities Heavy load
  • Dimension plate in mm 60x60
  • Distance between axes in mm 45x45
  • Diameter of fixation in mm M6
  • Wheel width in mm 40
  • Brake With brake
  • Uses Castor industrial
  • Width of the bearing band in mm 40
  • Profile type Dish
  • Offset in mm 22.5
  • Dimensions in mm 85
  • Maximum speed in km/h 1
  • Minimum / Maximum Temperature in °C -20/+80
castors

Castor EXTRA-LOW HEAVY-DUTY CASTOR DIAMETER 50 MM HEIGHT 72 MM LOAD 150 KG - SURB 50 PAF

Castor lowered diameter 50 mm

Details
Add to Compare Remove from Compare
Castor EXTRA-LOW WITH STRONG BRAKE LOAD DIAMETER 35 MM HEIGHT 66 MM LOAD 100 KG - SURB 35 PAF • Caujolle
  • New
  • Diameter of the wheel in mm 35
  • Load capacity in kilograms 100
  • Material of the tread Polyurethane
  • Type of bearing Bearing ball bearing
  • Type fixation Pivoting to plate (plate)
  • Height of the roulette in mm 67
  • Specificities Heavy load
    Non-staining
  • Dimension plate in mm 60x48
  • Distance between axes in mm 48x35
  • Diameter of fixation in mm M6
  • Wheel width in mm 27
  • Brake With brake
  • Width of the bearing band in mm 25
  • Offset in mm 15
  • Dimensions in mm 72
  • Maximum speed in km/h 1
  • Minimum / Maximum Temperature in °C -20/+80
handling-and-industry-castor-wheels

Castor EXTRA-LOW WITH STRONG BRAKE LOAD DIAMETER 35 MM HEIGHT 66 MM LOAD 100 KG - SURB 35 PAF

Castor extra low with brake diameter 35 mm

Details
Add to Compare Remove from Compare
