Castor ALL-TERRAIN WHEEL FOR OBSTACLE DIAMETER 250 MM LOAD 450 KG - TITAN FIXED SERIES 250

REF: 99885

The uniqueness of this model lies in the flexibility of the rubber combined with high wear resistance. This product has been designed to roll continuously on airport tarmacs. The treads allow for regular water evacuation to increase grip. The diameter of 250 mm allows for passing obstacles of 12.5 mm, such as gravel present on the path.

The frame consists of a steel fork with an epoxy paint thickness of 10 mm and an plate of extreme robustness made of 17 mm thick steel. The galvanized steel rim is made from 4 mm thick steel (twice that of a standard rim). The metal frame is fixed, and the wheel does not pivot.

The ride is very comfortable thanks to the sealed 2 RS ball bearings.

The tire is very strong, but the rubber remains flexible with a hardness of 70 Sh A.

Payment Secure
Add to Compare Remove from Compare

Technical sheet

  • Diameter of the wheel in mm 250

  • Load capacity in kilograms 450

  • Material of the tread Rubber

  • Type of bearing Bearing ball bearing

  • Type fixation Fixed to plate

  • Height of the roulette in mm 305

  • Specificities Heavy load

  • Bore in mm 20

  • Dimension plate in mm 175x140

  • Distance between axes in mm 140x105

  • Diameter of fixation in mm M14

  • Wheel width in mm 84

  • Hub length in mm 75

  • Width of the bearing band in mm 75

  • Profile type Dish

  • Offset in mm 80

  • Shore hardness 70 Sh A

  • Maximum speed in km/h 4

  • Minimum / Maximum Temperature in °C -20/+80

  • Weight 9.659 Kg
