REINFORCED RUBBER SWIVEL CASTOR DIAMETER 160 MM MAX LOAD 200 KG - S74C160

REF: 22211

This goods handling swivel castor with fixing plate, diameter 160 mm, is composed of a galvanised steel mounting.

The black rubber tread is mounted on a black plastic rim with threadguard and roller-bearings. The threadguard is particularly useful to prevent impurities being caught up in the bearings.

The castor swivels on two rows of bearings. It is ideal for goods handling in the workshop on uneven floors, but is also useful for giving extra height to a coffee table in the sitting room.

A castor for moving very heavy loads, silently.

Payment Secure

Technical sheet

  • Diameter of the wheel in mm 160

  • Load capacity in kilograms 200

  • Material of the tread Rubber

  • Type of bearing Roller bearing

  • Type fixation Pivoting to plate (plate)

  • Height of the roulette in mm 200

  • Bore in mm 20

  • Dimension plate in mm 136x110

  • Distance between axes in mm 105x80

  • Diameter of fixation in mm M10

  • Wheel width in mm 35

  • Width of the bearing band in mm 22

  • Offset in mm 55

  • Dimensions in mm 135

  • Maximum speed in km/h 4

  • Minimum / Maximum Temperature in °C -20/+80

  • Weight 2.334 Kg
