Castor FIXED NYLON DIAMETER 100 MM LOAD 1200 KG - STEC NYLON 100F

REF: 26155

This castor of very robust design can consistently support over 1200 kg per unit in dynamic and static load. The nylon helps to prevent crushing over the long term. The low coefficient of friction allows for easy rolling on smooth surfaces. A very high-performance bearing with steel rings helps to reduce the effort required to push the cart. The difference between a wheel with or without bearing corresponds to an effort that is multiplied by 3.

Payment Secure
Add to Compare Remove from Compare

Technical sheet

  • Diameter of the wheel in mm 100

  • Load capacity in kilograms 1200

  • Material of the tread Nylon

  • Type of bearing Bearing ball bearing

  • Type fixation Fixed to plate

  • Height of the roulette in mm 150

  • Specificities Heavy load

  • Bore in mm 25

  • Dimension plate in mm 138x110

  • Distance between axes in mm 105x75-80

  • Diameter of fixation in mm M10

  • Wheel width in mm 60

  • Hub length in mm 60

  • Width of the bearing band in mm 55

  • Shore hardness 80 Sh D

  • Maximum speed in km/h 4

  • Minimum / Maximum Temperature in °C -30/+80

  • Directional lock Optional

  • Weight 2.352 Kg
