S80 200P • Caujolle

S80 200P

REF: 26175

Discover our swivel caster with very high resistance, specifically designed for industrial applications and the handling of exceptionally heavy loads. Considered a true professional equipment, this caster combines robustness and reliability to optimize your most demanding operations.

  • Reinforced Mechanically Welded Frame: The frame is made of thick steel, mechanically welded to ensure maximum strength and rigidity, providing flawless durability even under intense stress.

  • High-Performance Wheel: The wheel has a diameter of 200 mm, ideal for overcoming obstacles while maintaining good stability.

  • Composition of Wheel: It is equipped with a polyurethane band offering excellent resistance to wear, cuts, and shocks. The cast iron rim ensures exceptional load capacity.

  • Ball Bearing Hub: The wheel is mounted on a ball bearing hub ensuring smooth pivoting and rolling, requiring less effort to move very heavy loads.

Thanks to its extremely solid construction, this caster is the perfect choice for:

  • Very Heavy Handling / Heavy Loads

  • Heavy Machine Equipment (on trolleys, platforms, or mobile benches)

  • Castors Relevables (for optimal stability)

  • Industrial Environments, Production Workshops, and Warehouses

  • Any application requiring equipment capable of supporting significant tonnages.

Payment Secure

Technical sheet

  • Diameter of the wheel in mm 200

  • Load capacity in kilograms 1000

  • Material of the tread Polyurethane

  • Type of bearing Bearing ball bearing

  • Type fixation Pivoting to plate (plate)

  • Height of the roulette in mm 250

  • Dimension plate in mm 150x110

  • Distance between axes in mm 121x105/80x59

  • Diameter of fixation in mm M12

  • Wheel width in mm 50

  • Offset in mm 65

  • Dimensions in mm 165

  • Maximum speed in km/h 4

  • Minimum / Maximum Temperature in °C -20/+80

  • Weight 7.180 Kg
