Castor DOUBLE Wheel INFLATED LARGE FORMAT DIAMETER 400 MM LOAD 1000 KG - S20-1 400 DOUBLE INFLATED • Caujolle
  • Castor DOUBLE Wheel INFLATED LARGE FORMAT DIAMETER 400 MM LOAD 1000 KG - S20-1 400 DOUBLE INFLATED
  • Castor DOUBLE Wheel INFLATED LARGE FORMAT DIAMETER 400 MM LOAD 1000 KG - S20-1 400 DOUBLE INFLATED
  • Castor DOUBLE Wheel INFLATED LARGE FORMAT DIAMETER 400 MM LOAD 1000 KG - S20-1 400 DOUBLE INFLATED
  • Castor DOUBLE Wheel INFLATED LARGE FORMAT DIAMETER 400 MM LOAD 1000 KG - S20-1 400 DOUBLE INFLATED

Castor DOUBLE Wheel INFLATED LARGE FORMAT DIAMETER 400 MM LOAD 1000 KG - S20-1 400 DOUBLE INFLATED

REF: 23450

Opt for a high-performance and ergonomic handling solution. Thanks to its twin pneumatic wheels of large diameter, this caster effectively absorbs shocks and easily overcomes obstacles on all types of surfaces (construction sites, earth, gravel, uneven floors).

Its double wheel design allows for better weight distribution, significantly reducing the pushing effort when moving very heavy loads. Its ultra-reinforced welded structure ensures excellent durability, while the ball bearing provides smooth and effortless rotation during maneuvers.

  • Difficult surfaces: Ideal for easily moving loads over rough terrain and uneven surfaces.

  • Effort reduction: The double wheel configuration reduces rolling resistance and simplifies the movement of very heavy objects.

  • Enhanced robustness: Structure with reinforced steel frame and steel sheet rims for high wear resistance.

  • Excellent rolling quality: Equipped with ball bearings for smooth rotation and a long lifespan.

  • Manoeuvrability: Swivel plate for quick and easy direction changes.

  • Recommended use: Particularly suited to the needs of professionals in industry, construction, heavy handling, and event management.

Technical specifications:

  • Type: Double swivel caster

  • Wheel diameter: 400 mm

  • Tread: Pneumatic (inflated wheels)

  • Rim material: Steel sheet

  • Frame: Reinforced steel

  • Type of bearing: Ball bearing

  • Type of attachment: Screw-in base plate

  • Use: Professional / Uneven surfaces

Payment Secure

Technical sheet

  • Diameter of the wheel in mm 400

  • Load capacity in kilograms 700

  • Material of the tread Inflatable rubber

  • Type of bearing Bearing ball bearing

  • Type fixation Pivoting to plate (plate)

  • Height of the roulette in mm 480

  • Specificities Heavy load

  • Dimension plate in mm 185x133 equals 24,605.

  • Distance between axes in mm 135x85 equals 11,475.

  • Diameter of fixation in mm M14

  • Width of the bearing band in mm 170x2 translates to 340 in English.

  • Maximum inflation pressure in bar 1.38BAR / 20PSI

  • Maximum speed in km/h 4

  • Minimum / Maximum Temperature in °C -40/+80

  • Type of valve Valve TUBELESS TR413

  • Weight 42.000 Kg
